Light Sources：1PCS x 150W LEDs
Beam Angle: 2°/4°/6°/8°/10°/11° 3°/6°/9°/12°/15°(Zoom Lens)
Gobo beam angle:Fixed Disc:10°-17°(Zoom Lens)
Rotation Disc:10°-15°(Zoom Lens)
Wash beam angle:15°-28°
DMX Channel: 17/20 channels
DMX Channel Control Mode:DMX,Master/Slave,Sound Control
Software upgrade: through DMX connection update the software
X axis /Y axis: 540 degree /270 degree X axis /Y axis precision: 16 bit precision scanning, magnetic positioning system,
can accurately automatically correct the Y axis position X axis position
Color Display: LCD color display
DMX signal input & output: 3 pin & 5 pin DMX socket
Socket outlet: PowerCon input / output
Protection grade: IP20 linear focusing system
Color disk: 8 fixed color plus white, two-way rainbow effect
Pattern plate: 1 fixed pattern plates, 7 patterns with white circle, 1 rotating pattern plates, 6 patterns and white circles
Pattern outer diameter: 21mm,pattern inner diameter: 17mm 1 bi-directional rotating 6 prism Wheel: 1 color wheel with 8 colors+open
Inner box size:380x322x470mm
Weight:14KG
