Rated voltage: AC100~240V 50/60Hz
Rated power:<300W
Scanner: 30kpps , scan angle:±30°;Input signal:±5V;Linearity distortion<2%
Motor: 3 phase 42 motor 2pcs
X axis 540° rotation,Y axis 270° rotation
Modulation:TTL
Beam diameter and divergence:5mm;<2mrad
Control mode:music (black out)/ automatic/master-slave/DMX512(19CH)
Demonstration effect:built-in 160 pattern
DMX effect:single pattern mode,and with the function of unique blanking,strobe, rotating, movement, zoom,write in,speed and color etc.
Control technology: ①RDM data bidirectional transmission ②temperature control system ③DMX512 upgrade
Operating requirement: dry, less dust, 10~35℃(environmental temperature),will reduce the attenuation of the diode and extend the life of the light.
Application:disco, club, medium indoor venue, festival
